LUPUSEC - XT Keypad V2
The LUPUSEC Keypad!The Keypad allows you to control your smart home alarm panel
The LUPUSEC-XT Keypad allows you to control, arm, and disarm your alarm panel. The keypad is battery powered and connects wirelessly to your XT alarm panel. Hence, you do not need to hassle with any wiring. Simply install the keypad and connect it wirelessly with the alarm panel - it's as simple as that!
Huge functionalityEasy control of users and pin codes:
Depending on which PIN code you use, you can control both areas of your alarm panel. In the web interface of your alarm panel, you can create up to 50 PIN codes per area and assign them with a name and certain rights. Hence, you can always check in the logs when and by whom a code was used. Security anytime and anywhere - with the free APP and push notifications.
The LUPUSEC alarm system:Broad expandability - The LUPUSEC alarm system:
We offer a wide variety of sensors and accessories that you can control and program in your smart home alarm system. You can integrate door contacts, IP cameras, motion detectors, mechanical and magnetic locks, shutter relays, and heating controls with just a view easy clicks to your smart home alarm panel.
- Tech. Data
-
LUPUSEC - Keypad V2
Technical data:
Dimensions 115 x 80 x 20mm (4.52 x 3.14 x 0.78 inch) (HxWxD) Weight 0.14 kg (0.3 pounds) Access option 4-digit pin code Lighting Yes, blue Tampering protection Yes Tampering protection displayed in the web interface Yes Status display Yes Status checked by the alarm panel Yes Status displayed in the alarm panel Yes Battery status displayed in the alarm panel Yes Battery status checked in the alarm panel Automatically Radio frequency 868,6625 MHz Radio performance max. 10mW(10dBm) Transmission range Approx. 30 to 100m (32 to 109 yards) depending on the local conditions Modulation FM Mounting options Screwing Power supply CR123 3V Average battery life 4 years Place of installation Wall
Only indoorsConforms to the following standards CE, FCC, RoHs, EN 50131 Grade 2 Functions Toggle arm-, disarm-, and home mode, silent-, fire-, and medical alarm, check alarm panel status Working environment -10°C to 45°C (14F to 113F) Air humidity Max. 85% Encryption Rolling Code Compatible with XT alarm panel XT1 Plus, XT2, XT2 Plus (Rolling Code Firmware installed), XT3, XT4 Includes:
Keypad Batteries Screws and dowels Manual - Downloads
